Pont Bailey Dur wedi'i Customized Irvine O Bris Ffafriol
video

Pont Bailey Dur wedi'i Customized Irvine O Bris Ffafriol

Quick Details Standard: AiSi Grade: Q345B-Q460C Place of Origin: Jiangsu, China Brand Name: BAILEY Model Number: CB100(CB321)Bailey Bridge Type: Heavy Application: Steel Structure Bridge Tolerance: ±3 percent Delivery Time: 15-21 days Product Name: Good Price bailey bridge dimensions Customized Other...
Anfon ymchwiliad
Sgwrs Nawr

Disgrifiad

Paramedrau technegol



Manylion Cyflym

Safon: AiSi

Gradd: Q345B-Q460C

Man Tarddiad: Jiangsu, Tsieina

Enw'r Brand: BAILEY

Rhif Model: CB100(CB321) Pont Bailey

Math: Trwm

Cais: Pont Strwythur Dur

Tolerance: ±3 percent

Amser Cyflenwi: 15-21 diwrnod

Enw Cynnyrch: Da Price dimensiynau pont beili Customized

Enw Arall: Dimensiynau pont Bailey

Taliad: L / C, T / T, ESCROW

MOQ: 1 PC

Porthladd: Shanghai

Manylion Cyflwyno: Yn ôl y gorchymyn

Gallu Cyflenwi: 10000 tunnell / tunnell y flwyddyn

Packing: 40' standard HQ containers


Gallu Cyflenwi

Gallu Cyflenwi: 10000 tunnell / tunnell y flwyddyn dimensiynau pont beili


Cyflenwi Pecynnu

Packaging Details: Bailey bridge dimensions packing: 40' standard HQ containers

Porthladd: Shanghai

ZB200 truss wasg tabl cyfyngedig
Nac ydw
grym mewnol
ffurf strwythur
model heb ei atgyfnerthu
model wedi'i atgyfnerthu
SS
DS
TS
QS
SSR
DSR
TSR
QSR
200
moment truss safonol (kN.m)
1034.3
2027.2
2978.8
3930.3
2165.4
4244.2
6236.4
8228.6
200
cneifiwch cyplau safonol (kN)
222.1
435.3
639.6
843.9
222.1
435.3
639.6
843.9
201
moment trawst plygu uchel (kN.m)
1593.2
3122.8
4585.5
6054.3
3335.8
6538.2
9607.1
12676.1
202
cneifio trawst plygu uchel (kN)
348
696
1044
1392
348
696
1044
1392
203
Grym cneifio cyplau cneifio uchel iawn (kN)
509.8
999.2
1468.2
1937.2
509.8
999.2
1468.2
1937.2
ZB200 Table of geometric characteristics of truss bridge（Half bridge）
strwythur
gnodweddion eometrigcs
nodweddion geometrig
arwynebedd cord (cm2)
Section properties（cm3）
Moment o syrthni (cm4)
ss
SS
25.48
5437
580174
SSR
50.96
10875
1160348
DS
DS
50.96
10875
1160348
DSR1
76.44
16312
1740522
DSR2
101.92
21750
2320696
TS
TS
76.44
16312
1740522
TSR2
127.4
27185
2900870
TSR3
152.88
32625
3481044
QS
QS
101.92
21750
2320696
QSR3
178.36
38059
4061218
QSR4
203.84
43500
4641392


Tagiau poblogaidd: addasu pont beili dur irvine o bris ffafriol, Tsieina, gweithgynhyrchwyr, ffatri, cyfanwerthu, rhad
